Product Summary

Datasheets 6N137, HCNW137/26zz, HCPL-zzzz
Product Photos 8-SOIC
Standard Package 100
Category Isolators
Family Optoisolators - Logic Output
Series -
Voltage - Isolation 3750Vrms
Number of Channels 2, Unidirectional
Current - Output / Channel 50mA
Data Rate 10Mbps
Propagation Delay High - Low @ If 50ns @ 7.5mA
Current - DC Forward (If) 20mA
Input Type DC
Output Type Open Collector
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package 8-SO
Packaging Tube
Other Names 516-1088-5

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
HCPL-0630
HCPL-0630
Avago Technologies
High Speed Optocouplers 10MBd 2Ch 5mA
Data Sheet
0-150: $2.18
150-250: $1.97
250-500: $1.85
500-1000: $1.75
HCPL-0630#500
HCPL-0630#500
Avago Technologies
High Speed Optocouplers 10MBd 2Ch 5mA
Data Sheet
0-885: $1.88
885-1500: $1.76
1500-3000: $1.66
HCPL-0630-000E
HCPL-0630-000E
Avago Technologies
High Speed Optocouplers 10MBd 2Ch 5mA
Data Sheet
0-1: $3.01
1-25: $2.46
25-100: $2.18
100-250: $1.97
HCPL-0630-500E
HCPL-0630-500E
Avago Technologies
High Speed Optocouplers 10MBd 2Ch 5mA
Data Sheet
0-1: $3.04
1-25: $2.48
25-100: $2.21
100-250: $1.99
